5 Tacheometric survey Tachometry is a method of measuring both horizontal distance and vertical elevation of a point in the distance, without the use of sophisticated technology, such as electronic distance measurement (EDM) or satellite transmissions 6The rope method used to set out a line perpendicular to the base line, starting from a point which is not on the base line;The Public Land Survey System (PLSS) is the surveying method developed and used in the United States to plat, or divide, real property for sale and settling Also known as the Rectangular Survey System, it was created by the Land Ordinance of 1785 to survey land ceded to the United States by the Treaty of Paris in 17, following the end of the American Revolution
